AI Trainer Kit with components
Compute & Master Xeon Servers
GOTT Trainer Kit
GOTT Trainer Kit
Digital Manufacturing and Precision Engineering Lab
3D Printer – FDM Elegoo Orange Storm Giga; FDM/FFF technology; Build volume: 1000 × 1000 × 1000 mm; filament-based extrusion; suitable for large-format component printing and engineering thermoplastics
3D Printer (FDM) – Bambu Lab X1 Carbon Combo FDM/FFF additive manufacturing system; enclosed high-speed 3D printer; multi material/multi-colour printing capability through Combo configuration; automated bed levelling and print monitoring; suitable for engineering-grade filament-based prototyping
3D Scanner – Creality CR Scan Lizard Premium: Non-contact optical 3D scanner; high-precision surface scanning; captures geometrical details of physical objects and converts them into digital 3D models/mesh data; suitable for small and medium-sized components
Digital Tachometer: Digital rotational-speed measuring instrument; electronic display; suitable for RPM measurement of rotating machinery; exact make, measuring range, resolution and accuracy are not specified in the invoice
CO₂ Laser Cutting Machine SIL Accucut 1212; CO₂ laser-based cutting and engraving system; computer-controlled X– Y motion; suitable for sheet-type non-metallic materials
Bench Top Drill Machine Bench-mounted drilling machine; variable spindle operation depending on selected speed; adjustable work table; chuck-based drill holding arrangement
Bench Grinder Bosch; bench-mounted electric grinder; dual grinding-wheel arrangement typical of this equipment category.
Circular Saw Bosch; electrically operated circular-blade cutting machine; adjustable cutting arrangement depending on model
Belt and Disc Sanding Machine Voltz Belt and Disc Sanding Machine; combined belt and rotating-disc sanding arrangement
Mitre Saw Bosch; circular blade with adjustable mitre-angle cutting mechanism; bench-mounted cutting arrangement
Scroll Saw Makita; reciprocating fine blade; suitable for intricate and curved profiles
Bosch Angle Grinder Bosch make; handheld electric angle grinder; 4-inch grinding/cutting wheel; highspeed spindle; side-handle arrangement; compatible with grinding, cutting and finishing discs; exact model, motor power and RPM are not specified in the invoice
Bosch Jig Saw Bosch make; electrically operated reciprocating-blade saw; handheld configuration; replaceable jigsaw blade; suitable for straight, curved and profile cutting; exact model, power, stroke rate and cutting capacity are not specified
Bosch Table Saw Bosch make; bench/tablemounted circular saw; rotating circular cutting blade; worksupport table and guiding arrangement; suitable for controlled straight cutting; exact model, blade diameter, power and cutting depth are not specified
Bosch Random Orbit Sander Bosch make; handheld electric orbital sanding machine; random-orbit sanding action; circular abrasive-disc arrangement; suitable for uniform surface finishing
Bosch Planer Bosch make; handheld electric planer; rotating cutter/blade mechanism; adjustable material removal depth depending on model; exact model, cutting width, planing depth, power, and speed are not specified
PCB Manufacturing Lab
MonoFab SRM-20 PCB Milling Machine - The MonoFab SRM-20 supports PCB prototyping through milling-based fabrication.
Key Capabilities
• PCB Milling
• Circuit Prototyping
• Design to Finished Product
• 3D Milling
• Prototype Development
Voltera V1 PCB Printer with Drill Attachment - The Voltera V1 is an additive PCB prototyping system equipped with PCB printing and drilling capabilities.
Key Capabilities
• Rigid PCB Printing
• Flexible PCB Printing
• Wearable PCB Development
• Through-Hole Drilling
• Rapid PCB Prototyping
The facilities support a range of academic, research, and prototype-development applications: Wearable Technology, Antenna Design, Multilayer Prototyping for IoT, Robotics and AI, Customized Circuit Boards, Automation and Test Engineering, Research Applications, Commercial Applications
Robotics and Automation Lab
Fire Bird V 2560 - Educational & Research Mobile Robot
Key Features
• ATmega2560 microcontroller with Arduino IDE / AVR Studio support
• Dual DC geared motors
• IR proximity, white-line and Sharp distance sensors
• USB, UART, Bluetooth/XBee connectivity
• Motor drivers and LCD interface
• Buzzer, switches and battery monitoring
• Multiple I/O and sensor ports
Fire Bird V LPC2148 - Embedded Robotics Development Platform
Key Features
• 32-bit ARM7 LPC2148 microcontroller
• IR proximity, Sharp distance and line sensors
• Accelerometer
• DC geared motors with PWM control
• Wheel encoders
• UART, SPI and I²C interfaces
• On-board LCD, buzzer and LEDs
• Battery management and regulated power supply
• Bluetooth/ZigBee and other add-on support
BAW Miter Saw– J1X-BW-255 - Workshop Fabrication Equipment
Key Features
• Blade Diameter: Ø 255 mm
• No-load Speed: 6000 RPM
• Rated Input Power: 1800 W
• Rated Voltage: 220 V AC
• Rated Frequency: 50 Hz
• Manufacturer: Zhejiang BAW Tools
SP-2000 Single-Output Power Supply - 2 kW AC/DC Power Supply
Key Features
• 2 kW single-output enclosed AC/DC power supply
• 90–264 VAC input range
• 1U low-profile design
• Efficiency up to 92%
• Programmable output voltage
• Active current sharing
• Remote ON/OFF control
• Remote sensing
• Auxiliary power output
• Short-circuit, overload and over-voltage protection
Oilless Air Compressor – SF-300F Pneumatic Support System
Key Features
• Capacity: 150 L/min
• Pressure: 0.8 MPa
• Power: 1 HP
• Speed: 1440 RPM
• Tank: 30 L
• Voltage: 220 V / 50 Hz
Green Skills and AI Center and IOT Lab
Cell Charging and Discharging Workbench
• Controlled Charging – Charges individual battery cells using predefined CC, CV, or CC-CV charging methods.
• Controlled Discharging – Discharges the cell at a specified current or load to study its discharge behaviour.
• Voltage and Current Measurement – Continuously measures and records cell voltage and charging/discharging current.
• Capacity and Energy Calculation – Determines the cell capacity (Ah) and energy delivered/stored (Wh).
• Performance Monitoring – Monitors parameters such as SoC and temperature.
Battery Pack Load Testing Workbench
• Battery Pack Voltage Measurement – Measures pack voltage under no-load and load conditions.
• Load Current Measurement – Measures the current drawn from the battery during testing.
• State of Charge (SoC) Evaluation – Monitors the change in SoC during discharge.
• Data Logging – Records voltage, current, power, parameters for analysis.
• Discharge Characteristic Analysis –Generates voltage/current versus time characteristics.
• Battery Health Assessment – Helps identify capacity degradation and abnormal battery behavior.
EV IOT and Telematics Workbench
• Real-Time Vehicle Monitoring – Monitors EV parameters such as battery voltage, current, SoC, speed, and temperature.
• Data Communication & Cloud Connectivity – Transfers vehicle data to a cloud/server platform using IoT communication technologies.
Battery BMS with CAN Protocol
• Cell Voltage Monitoring – Monitors individual cell voltages and detects abnormal voltage conditions.
• Temperature Monitoring – Measures battery temperature to prevent overheating and thermal-related faults.
• SoC and SoH Estimation – Calculates the battery State of Charge (SoC) and State of Health (SoH).
• Cell Balancing – Maintains uniform voltage levels among cells using active or passive balancing techniques.
Intel Unnati and Vision Digital India Lab
GPU Node : 2U Dual Socket Server Solution (5th Gen 6530) –suitable for running demanding AI/ML workloads, including Gen-AI, HPC , and other data-intensive applications.
• Ubuntu* 18.04
• Intel® oneAPI Base Toolkit
• Intel® AI Analytics Toolkit
• Horovod* + Intel® MPI (for distributed DL training with TensorFlow*)
• Intel® Extension for PyTorch* (IPEX)
• Intel® Distribution of OpenVINOTM Toolkit
Login and Storage Server with 5th Gen Intel® Xeon® 4510Y - designed to handle both user authentication (login functionalities) and storage management needs for AI, HPC, and data-heavy applications
16-Port unmanaged Gigabit Ethernet Switch + patch cables + power cables + server Rack along with standard accessories OpenVinoTMlabs will be run on Intel® DevCloud for the Edge.
Signage and Sun Board Posters (1 Set) as per Intel® Recommendations: This section provides a detailed breakdown of the lab branding for the Intel® Unnati Labs, ensuring that all materials are aligned with Intel®’s official guidelines for effective and professional branding.
